HM-6040HP-6

Detailed



This model is assembled in strict accordance with the export quality standards.

Assembled by senior technical engineers over eight years.

rigging, binding, sling rope 、safety belts and other belt products are designed for sewing . The sewing lines are even and beautiful, and the pulling force is stable.

The thickest can sew 1500D*3 thread.

The efficiency is equivalent to 8-15 times that of traditional production methods.

The cutting thread of this machine is more stable under the high-speed sewing of thick material, and the traditional thick material model does not cut the thread.

Multiple segment clamp, more smooth thread duringthe sewing process, to ensure that the product tension is more uniform.



The new touch screen is more colorful, more convenient button function, one-button start, lift foot and bottom thread.


The three times rotary hook can reach about 120meters.

Save workers' time and cost.

Reduce the bottom line by more than 60%.


Huamei adopts automatic winding device . The blade clamps the thread head and puts the bobbin to automatically wind the thread.

The winding is even and the yield rate of the sewn product is high.




Specific

Model No

HM-6040HP-6

Stitching type

Single needle, lock stitch

Working Area

600*400mm

Stitching length

0.1-16MM

Speed

2800RPM/MIN

Sewing Thickness

20mm

Max. Stitches

10000 stitches/pattern

Maximum number of patterns

Store 1000 fuselage design, external usb design for unlimited

Hook

six times rotary hook

Machine needle

DY*3 27# 28#

Needle cooling device

Yes

Lifting height of internal presser foot

28MM

Hook’s auto-oil and chean

Yes

Presser foot form of middle presser foot

MOTOR

Stepping foot stroke

4-10mm

Work holder lift height

30mm

Voltage

AC, 220 v, with grounding protection

Dimensions (with packaging)

1300MM*1300MM*1450MM

Weight /Package

250KG/ wooden case

PACKAGE

WOODEN CASE
