Detailed
High efficiency due to automatic functions like thread trimming, automatic backtacking and pneu- matic sewing foot lift.
Increased performance due to additional functions like integrated second stitch length, additional thread tension and quick stroke adjustment.
The large clearance and the slim sewing head allows easy handling of large workpieces.
The sewing foot lift up to 20 mm facilitates the in- sertion and removal of bulky workpieces.
The sewing foot stroke up to 9 mm enables safe sewing of materials with large differences in height.
Increased productivity due to the XL hook( 28 mm, 70% higher bobbin capacity in compari- son to the standard hook,∅28 mm) Also available with L-hook (0 26 mm),(867-190322-M.
Universal sewing operations in the field of medium-heavy duty applications Performance features.
Max. stitch length 12mm.
Thread sizes up to max. Tkt.10/3.
Max. Sewing speed.
